Tuesday, December 05, 2023

Generating synthetic data

 Faker is an excellent tool for generating mock data for your application. But any complex application would have tens of tables with complex relationships between them. How can we use Faker to populate all of these tables?

We can follow two approaches here:

Option 1: Create the primary table first and then the dependent tables. Then when populating the dependent tables, you can refer to a random primary key from the first table. A good article summarizing this is here -- https://khofifah.medium.com/how-to-generate-fake-relational-data-in-python-and-getting-insight-using-sql-in-bigquery-985c5adc87d3

Code snippet:
 #generate relational user id in account table and transaction table
trans['user_id']=random.choices(account["id"], k=len(trans))

Option 2: Use a ORM framework to insert data into the database. An ORM framework would make it easy to establish relationships between different tables. A good article on this approach is here - https://medium.com/@pushpam.ankit/generating-mock-data-for-complex-relational-tables-with-python-and-sqlite-2950ab7700f2

Another interesting opensource tool is "Synthetic Data Vault" https://sdv.dev/
In these tools, we first train the tool on real data and then use the AI model for generation of new synthetic data. Many vendors differentiate between "mock" and "synthetic" data on this aspect.

Sunday, November 05, 2023

Fine-tuning vs RAG for LLMs

Large language models (LLMs) have revolutionized the field of natural language processing (NLP), enabling state-of-the-art performance on a wide range of tasks, including text classification, translation, summarization, and generation.

When it comes to usecases around leveraing LLMs for extracting insights from our own knowledge repositories, we have broadly two design approaches:

  • Fine-tuning a LLM
  • RAG (Retrieval Augmented Generation)

Many fields have their own specialised terminology. This vocabulary may be missing from the common pretraining data utilised by LLMs.

Fine Tuning a LLM
The process of fine-tuning a pre-trained LLM on a fresh domain-specific dataset is known as fine-tuning. Fine-tuning is the process of further training a previously trained LLM on a smaller, domain-specific, labelled dataset.
To fine-tune an LLM, you'll need a dataset of labelled data, with each data point representing an input and output pair. A written passage, a query, or a code snippet might be used as input. The result might be a label, a summary, a translation, or code.
Once you have a dataset, you can use a supervised learning method to fine-tune the LLM. By minimising a loss function, the algorithm will learn to map the input to the output.
It can be computationally costly to fine-tune an LLM.

Another subset of the above approach is called PEFT (Parameter-efficient fine-tuning) and LoRA is the most popular approach for PEFT today.
LoRA (Low-Rank Adaptation of Large Language Models) is a fine-tuning approach for LLMs that is more efficient and memory-efficient than standard fine-tuning. Traditional fine-tuning entails altering all of an LLM's parameters. This can be computationally expensive and memory-intensive, particularly for big LLMs with billions of parameters.LoRA, on the other hand, merely modifies a few low-rank matrices. Because of this, LoRA is far more efficient and memory-efficient than conventional fine-tuning.

An excellent article explaining the concepts of full fine-tuning and LoRA is here -- https://deci.ai/blog/fine-tuning-peft-prompt-engineering-and-rag-which-one-is-right-for-you/

RAG (Retrieval Augmented Generation)
RAG is an effective strategy for improving the performance and relevance of LLMs by combining "prompt engineering" with "context retrieval" from external data sources.
Given below is a high level process flow for RAG.
  1. All documents from a domain specific knoweldge source are converted into embeddings and stored in a special vector database. These vector embeddings are nothing but “N-dimensional matrices” of numbers.
  2. When the user types his query, even the query is converted into an embedding (matrix of numbers) using a AI model.
  3. Semantic search techniques are used to identify all contextual sentences in the “document-embedding” for the given query. Most popular algorithm is “cosine similarity”. This algorithm uses a cosine maths function to get all the sentences (matrices) that are ‘near’ or ‘close’ to the query (matrix). This entails matrix multiplications and other maths functions.
  4. All retrieved “semantically similar sentences/paragraphs” from multiple documents are finally again sent to a LLM for ‘summarization’. The LLM would paraphrase all the disparate sentences into a coherent story that is readable.
RAG along with Prompt Engineering can be used to build powerful knowlege management platforms such as this - https://www.youtube.com/watch?v=lndJ108DlBs

The table belows shows the advantages/disadvantages of both the approaches. For most usecases, a proper utilization of prompt engineering and RAG would suffice.

Friday, November 03, 2023

Ruminating on Debezium CDC

Debezium is a distributed open source platform for change data capture (CDC). It collects real-time changes to database tables and transmits them to other applications. Debezium is developed on top of Apache Kafka, which provides a dependable and scalable streaming data infrastructure.

Debezium operates by connecting to a database and watching for table updates. When a change is identified, Debezium creates a Kafka event with the change's information. Other applications, such as data pipelines, microservices, and analytics systems, can then ingest these events.

There are several benefits of utilising Debezium CDC, including:

  • Debezium feeds updates to database tables in near real time, allowing other applications to react to changes almost quickly.
  • Debezium is built on Apache Kafka, which provides a dependable and scalable streaming data platform.
  • Debezium can stream updates to a number of databases, including MySQL, PostgreSQL, Oracle, and Cassandra using connectors.
  • Debezium is simple to install and operate. It has connectors for major databases and may be deployed on a number of platforms, including Kubernetes/Docker.
Use cases for Debezium CDC:
  • Data pipelines and real-time analytics: Debezium can be used to create data pipelines that stream changes from databases to other data systems, such as data warehouses, data lakes, and analytics systems.  For example, you could use Debezium to stream changes from a MySQL database to Apache Spark Streaming. Apache Spark Streaming can then process the events and generate real-time analytics, such as dashboards and reports.

Wednesday, October 11, 2023

Mock data and APIs

Mocking APIs and synthetic mock data generation are invaluable techniques to speed up development. We recently used the Mockaroo platform and found it quite handy to generate dummy data and mock APIs.


IBM has also kindly released ~25M records of synthetic financial transacation data that can be used during application development or ML training.


Other examples of mock data generation tools are:

Leveraging Graph Databases for Fraud Detection

 There are many techniques for building Fraud Detection systems. It can be:

  • Rule Based (tribal knowledge codified)
  • Machine Learning (detect anomalies, patterns, etc.)
There is a third technique using Graph Databases such as Neo4J, TigerGraph or Amazon Neptune
A graph network can assist identify hidden aspects of transactions that would otherwise be missed just by looking at data in a relational table.

Lets consider the example of indenfying fraud in a simple financial transaction. Every financial transaction has thousands of attributes associated with is - e.g. amount, IP address, browser, OS, cookie data, bank, geo-location, card details, recepient,etc.
Using a graph database, we can build a graph network where each transaction is a node and the line connections (aka edges) represent the attributes of the transaction. The following article gives a good primer on how this kind of network would look like - https://towardsdatascience.com/fraud-through-the-eyes-of-a-machine-1dd994405e6e

Once the graph is created, there are many techniques that can be used to detect patterns and relationships between the different attributes.
  • Link Analysis: This approach is used to detect unusual links between network items. In a financial network, for example, you may check for linkages between accounts engaged in fraudulent activities.
  • Anomaly detection: This approach is used to identify entities or transactions that differ from usual behaviour in a network. In a credit card network, for example, you may watch for transactions performed from strange areas or for abnormally big sums.
  • Cluster Analysis:  This technique is used to identify groups of entities in a network that are closely connected to each other. Clustering may also be used to surface commercial ties or social circles in a transaction banking graph.
Thus, by employing graph analytics, we may detect clusters and links in their data, revealing previously unknown possible fraud connections. More information on such techniques can be found on this blog: https://www.cylynx.io/blog/network-analytics-for-fraud-detection-in-banking-and-finance/

Because of their capacity to track complicated chains of transactions, graph databases are particularly useful in financial crime use cases and fraud detection graph analysis. Traditional RDBMS struggle with these sequence of connections because multiple recursive inner joins are necessary to accomplish this sort of traversal query in SQL, which is very challenging.

A few articles that give good illustrations on this topic:

Friday, October 06, 2023

Defensive measures for LLM prompts

To prevent abusive prompts and prompt hacking, we need to leverage certain techniques such as Filtering, Post-Prompting, random enclosures, content moderation, etc.

A good explanation of these techniques is given here -- https://learnprompting.org/docs/category/-defensive-measures

Sunday, September 10, 2023

Ruminating on Clickjacking

Clickjacking is a sort of cyberattack in which people are tricked into clicking on something they did not plan to click on. This can be accomplished by superimposing a malicious frame on top of a legal website or injecting a malicious link within an apparently innocent piece of content.

When a user clicks on what appears to be a legitimate website or link, they are in fact clicking on a malicious frame or link. This can then redirect users to a bogus website or run malicious programmes on their PC.

Clickjacking attacks are sometimes difficult to detect because they frequently depend on social engineering tactics to deceive users. For example, the attacker may develop a phoney website that appears to be the actual one, or they could give the victim a link that appears to be from a valid source.

To protect yourself against clickjacking, make use of a pop-up blocker (default in Chrome and many modern browsers).  Any website that asks you to enable Flash or JavaScript should be avoided. Hover your cursor over a link before clicking on it if you are unsure whether it is authentic. If the URL of the link changes, it is most likely malicious.

If you are a developer, please check out the following links to what can be done in your code to reduce the risk of clickjacking.


Tuesday, August 15, 2023

Ruminating on Shadow Testing or Shadow Mirroring

Shadow testing is a software testing technique that involves sending production traffic to a duplicate or shadow environment. This allows testers to compare the behavior of the new feature in the shadow environment to the behavior of the old feature in the production environment. This can help to identify any potential problems with the new feature before it is released to all users.

The following diagram from the Microsoft GitHub site illustrates this concept.

The following blogs/articles explain this concept in good detail:

Monday, July 31, 2023

Ruminating on Differential Privacy

Differential privacy (DP) is a mathematical paradigm for protecting individuals' privacy in datasets. By allowing data to be analysed without disclosing sensitive information about any individual in the dataset, it can protects the privacy of individuals. Thus, it is a method of protecting the privacy of people in a dataset while maintaining the dataset's overall usefulness.

To protect privacy, the most easy option is anonymization, which removes identifying information. A person's name, for example, may be erased from a medical record. Unfortunately, anonymization is rarely enough to provide privacy because the remaining information might be uniquely identifiable. For example, given a person's gender, postal code, age, ethnicity, and height, it may be able to identify them uniquely even in a massive database.

The concept behind differential privacy is to introduce noise into the data in such a manner that it is hard to verify whether any specific individual's data was included in the dataset. This is accomplished by assigning a random value to each data point, which is chosen in such a manner that it has no effect on the overall statistics of the dataset but makes identifying individual data points more difficult.

The following paper by Apple gives a very good overview of how Apple uses Differential Privacy to gain insight into what many Apple users are doing, while helping to preserve the privacy of individual users - https://www.apple.com/privacy/docs/Differential_Privacy_Overview.pdf

Epsilon (ε) is a parameter in differential privacy that affects the amount of noise introduced to the data. A greater epsilon number adds more noise, which gives more privacy but affects the accuracy of the findings.

Here are some examples of epsilon values that might be used in different applications:

  • Healthcare: Epsilon might be set to a small value, such as 0.01, to ensure that the privacy of patients is protected.
  • Marketing: Epsilon might be set to a larger value, such as 1.0, to allow for more accurate results.
  • Government: Epsilon might be set to a very large value, such as 100.0, to allow for the analysis of large datasets without compromising the privacy of individuals.
Thus, the epsilon value chosen represents a trade-off between privacy and accuracy. The lower the epsilon number, the more private the data will be, but the findings will be less accurate. The greater the epsilon number, the more accurate the findings will be, but the data will be less private.
A deep dive into these techniques is illustrated in this paper - https://www.cis.upenn.edu/~aaroth/Papers/privacybook.pdf

Thursday, July 20, 2023

Ruminating on nip.io and Let's Encrypt

nip.io is a free, open-source service that allows you to use wildcard DNS for any IP address. This implies you may build a hostname that resolves to any IP address, no matter where it is. This may be beneficial for a number of things, including:

  • Testing local machine applications. When constructing a local application, you may utilise nip.io to provide it a hostname that can be accessed from anywhere. This makes it simpler to test and distribute the application with others. This service has been made free by a company called as Powerdns. Examples:
    • maps to
    • 192-168-1-250.nip.io maps to
    • 0a000803.nip.io maps to  (hexadecimal format)
  • Many online services expect a hostname and do not accept an IP address. In such cases, you can simple append *.nip.io at the end of the public IP address and get a OOTB domain name :)
  • Creae a SSL certificate using letsencrypt:  If you use the "dash" and "hexadecimal" notation of nip.io, then you can easily create a public SSL certificate using "Let's Encrypt" that would be honoured by all browsers. No need of struggling with self-signed certificates.
ngrok is another great tool that should be in the arsenal of every developer.

Monday, July 03, 2023

Ruminating on Observability

It is more critical than ever in today's complex and dispersed IT settings to have a complete grasp of how your systems are performing. This is where the concept of observability comes into play. The capacity to comprehend the condition of a system by gathering and analysing data from various sources is referred to as observability.

Observabilty has three critical pillars:

  • Distributed Logging (using ELK, Splunk)
  • Metrics (performance instrumentation in code)
  • Tracing (E2E visibility across the tech stack)

Distributed Logging: Logs keep track of events that happen in a system. They may be used to discover problems, performance bottlenecks, and the flow of traffic through a system. In a modern scalable distributed architecture, we need logging frameworks that support collection and ingestion of logs across the complete tech stack. Platforms such as Splunk and ELK (Elastic, Logstash, Kibana) support this and are popular frameworks for distributed logging.

Metrics (performance instrumentation in code): Metrics are numerical measures of a system's status. They may be used to monitor CPU use, memory consumption, and request latency, among other things. Some of the most popular frameworks for metrics are Micrometer , Prometheus and DropWizard Metrics

Tracing (E2E visibility across the tech stack): Traces are a record of a request's route through a system. They may be utilised to determine the core cause of performance issues and to comprehend how various system components interact with one another. A unique Trace-ID is used to corelate the request across all the components of the tech stack.

Platforms such as Dynatrace, AppDynamics and DataDog provide comprehensive features to implement all aspects of Observability.

The three observability pillars operate together to offer a complete picture of a system's behaviour. By collecting and analysing data from all three sources, you can acquire a thorough picture of how your systems operate and discover possible issues before they affect your consumers.

There are a number of benefits to implementing the three pillars of observability. These benefits include:

  • The ability to identify and troubleshoot problems faster
  • The ability to improve performance and reliability
  • The ability to make better decisions about system design and architecture

If you want to increase the observability of your systems, I recommend that you study more about the three pillars of observability and the many techniques to apply them. You can take your IT operations to the next level if you have a thorough grasp of observability.

Saturday, May 13, 2023

Ruminating on Prompt Engineering

There has been a lot of buzz in recent years about the potential of large language models (LLMs) to develop new text forms, translate languages, compose various types of creative material, and answer your queries in an instructive manner. However, one of the drawbacks of LLMs is that they may be quite unexpected. Even little changes to the prompt might provide drastically different outcomes. This is where quick engineering comes into play.

The technique of creating prompts that are clear, explicit, and instructive is known as prompt engineering. You may maximise your chances of receiving the desired outcome from your LLM by properly writing your questions.

Given below are some of the techniques you can use to create better prompts:

  • Be precise and concise: The more detailed your instruction, the more likely your LLM will get the intended result. Instead of asking, "Write me a poem," you may say, "Write me a poem about peace".
  • Use keywords: Keywords are words or phrases related to the intended outcome. If you want your LLM to write a blog article about generative AI, for example, you might add keywords like "prompt engineering," "LLMs," and "generative AI."
  • Provide context: Context is information that assists your LLM in comprehending the intended outcome. If you want your LLM to write a poetry about Spring, for example, you might add context by supplying a list of phrases around Spring.
  • Provide examples: Use examples to demonstrate to your LLM what you are looking for. For example, if you want your LLM to create poetry, you may present samples of poems you appreciate.
Andrew NG has created an online course to learn about prompt engineering here - https://www.deeplearning.ai/short-courses/chatgpt-prompt-engineering-for-developers/

In fact, the rise of LLMs has resulted in new job roles like "Prompt Engineer" as highlighted in the articles below:

Monday, January 16, 2023

API mock servers from OpenAPI specs

 If you have an OpenAPI specs file (YAML or JSON), then you can quickly create a mock server using one of the following tools.

A list of all other OpenAPI tools is given here: https://openapi.tools/
